Ayudh GM 5030 – 2″to 12″ Grooving Machine
PIPE GROOVING MACHINE
MODEL: AYUDH GM 5030
DESCRIPTION :-
- Model AYUDH GM5030 Electric Hydraulic Roll Grooving Machine is designed to roll grooves on steel pipes and stainless steel from 2″-12″ (DN50~DN300) SCH10/SCH20, 2″-8″ (DN50-DN200) SCH10/SCH40
- Appropriate for various daily tasks involving fire-fighting pipes, this roll groover is a comprehensive tool that includes a motor, hydraulic feeding pump, foot switch, and pipe stand.
- The motor’s built-in high-performance gear reduction system enables a compact design and reduced noise levels.
- The unique combination of the hydraulic feeding pump and the groove depth lock knob guarantees premium grooves and optimal efficiency.
SPECIFICATIONS :-
| Fabrication Capacity | 2″~8″ (DN50~DN200, Ø33~Ø219) SCH10/40 Steel Pipe 10″-12″ (DN250~DN300, Ø254~Ø325) SCH10/20 Steel Pipe |
| Power | 1100W |
| Max Wall Thickness | 8mm |
| Output Speed | 23 R.P.M |
| Gross Weight | 95 kgs |
| Packing Size | 75*40*70 cm |
SCOPE OF DELIVERY
- PIPE STAND
- DRIVE ROLLER (2-3″, 3-6″, 8-12″)
- GROOVE ROLLER (2-6″, 8-12″)
- FOOT SWITCH
